Synergetic Effect in Multilayer Coating Systems Ni–P–W and W–C Obtained by Chemical-Catalytic Metallization and Chemical Vapor Deposition

V. V. Dushik; Душик В. В.; E. A. Ruban; Рубан Е. А.; A. B. Drovosekov; Дровосеков А. Б.; A. A. Shaporenkov; Шапоренков А. А.; N. V. Rozhanskiy; Рожанский Н. В.

doi:10.31857/S102809602312004X

Synergetic Effect in Multilayer Coating Systems Ni–P–W and W–C Obtained by Chemical-Catalytic Metallization and Chemical Vapor Deposition

Autores: Dushik V.V.¹, Ruban E.A.¹, Drovosekov A.B.¹, Shaporenkov A.A.¹, Rozhanskiy N.V.¹
Afiliações:
1. Frumkin Institute of Physical Chemistry and Electrochemistry RAS
Edição: Nº 12 (2023)
Páginas: 54-62
Seção: Articles
URL: https://bakhtiniada.ru/1028-0960/article/view/232217
DOI: https://doi.org/10.31857/S102809602312004X
EDN: https://elibrary.ru/BDJJLH
ID: 232217

Citar

Texto integral

Acesso aberto
Acesso é fechado

Acesso está concedido
Acesso é fechado

Somente assinantes

Resumo
Sobre autores
Bibliografia
Arquivos suplementares
Estatísticas

Resumo

The interface features of the W–C system obtained by chemical vapor deposition and Ni–P–W layers of various compositions obtained by chemical-catalytic metallization are studied. Ni–P–W layers are used as support layers for coatings of the W–C system to improve the adhesive strength of the applied coatings to steels and resistance to loads directed along the normal to the surface. The methods of scanning electron microscopy, X-ray diffraction, and X-ray photoelectron spectroscopy have been used to study the morphology, phase and elemental composition of the obtained layers, as well as phase transformations occurring in the layers during heat treatment. Mechanical tests have shown that Ni–P layers with low phosphorus content, in terms of their characteristics, demonstrate the best support properties.

Palavras-chave

multilayer coatings, chemical vapor deposition, chemical-catalytic deposition, nickel, tungsten carbide.

Bibliografia

Ажогин Ф.Ф., Беленький М.А., Галль И.Е. и др. Гальванотехника: Справочник. М.: Металлургия, 1987. 736 с.
Анциферов В.Н., Бобров Г.В., Дружинин Л.К. и др. Порошковая металлургия и напыленные покрытия: Учебник для вузов. М.: Металлургия, 1987. 792 с.
Mattox D.M. Handbook of Physical Vapor Deposition (PVD) Processing. Noyes Publications, 1998. 945 p.
Pierson H.O. Hanbook of Chemical Vapor Deposotion (CVD). Principles, Technology and Application. Second Edition. Noyes Publications, 1999. 506 p.
Dushik V.V., Rozhanskii N.V., Lifshits V.O. et al. // Mater. Lett. 2018. V. 228. № 10. P. 164.
Dushik V.V., Redkina G.V., Rozhanskii N.V. et al. // Prot. Met. Phys. Chem. Surf. 2020. V. 56. № 7. P. 1321.
Dushik V.V., Lakhotkin Y.V., Kuzmin V.P. et al. // Prot. Met. Phys. Chem. Surf. 2018. V. 54. № 7. P. 1315.
Dushik V.V., Rozhanskii N.V., Zalavutdinov R.K. // J. Surf. Invest.: X-ray, Synchrotron Neutron Tech. 2019. V. 13. № 5. P. 919.
Högberg H., Tägtström P., Lu J., Jansson U. // Thin Solid Films. 1996. V. 272. Iss. 1. P. 116.
Riedel W. Electroless Nickel Plating. Hertfordshire: Finishing Publication LTD, 1991.
Krutskikh V.M., Drovosekov A.B., Ivanov V.M. // Russ. J. Electrochem. 2016. V. 52. № 9. P. 873.
Душик В.В., Рубан Е.А., Шапоренков А.А. и др. // Коррозия: материалы, защита. 2021. № 12. С. 15.
Душик В.В., Левдикова К.С., Шапоренков А.А. и др. // Коррозия: материалы, защита. 2022. № 2. С. 43.
Дровосеков А.Б., Алиев А.Д., Рожанский Н.В. // Практика противокоррозионной защиты. 2018. Т. 90. № 4. С. 9.
Дровосеков А.Б. // Практика противокоррозионной защиты. 2020. Т. 25. № 2. С. 66.
ГОСТ 9450-76. Измерение микротвердости вдавливанием алмазных наконечников. М.: Изд-во стандартов, 1977. 35 с.
ASTM C1624-05. Standard Test Method for Adhesion Strength and Mechanical Failure Modes of Ceramic Coatings by Quantitative Single Point Scratch Testing. 2015. 29 p.
Lassner E., Schubert W.D. Tungsten. Properties, Chemistry, Technology of the Element, Alloys, and Chemical Compounds. Springer, 1999. 422 p.
